Relay an toàn PILZ PNOZ XV3.1 3/24VDC 3n/o 1n/c 2n/o t (774532)

Relay an toàn PILZ PNOZ XV3.1 3/24VDC 3n/o 1n/c 2n/o t (774532)

Cám ơn bạn đã quan tâm đến sản phẩm của NTN.
Yêu cầu báo giá xin click vào đây.

Mr. Nam:

0982494745

Model: PNOZ XV3.1 3/24VDC 3n/o 1n/c 2n/o t

Maker: PILZ

Description: Rờ le an toàn

Safety relay (standalone), inputs: 1/2-channel wiring with/without detection of shorts across contacts, outputs: 3 N/O, 1 N/C,2 N/O t-d, UB = 24 V DC, width: 90 mm, screw terminals integrated, E-STOP monitoring, safety gates with 2 delay-on de-energi...

Supply voltage (V)	24 V
Type of supply voltage U1	DC
Power consumption DC	4.5 W

Utilisation cat. AC/DC1 stand.	EN 60947-4-1
Voltage AC1 safety cont.	240 V
Max. current AC1 safety cont.	8 A
Voltage DC1 safety cont.	24 V
Max. current DC1 safety cont.	8 A
Utilisation cat. AC15/DC13sta.	EN 60947-5-1
Voltage AC15 safety cont.	230 V
Max. current AC15 safety cont.	5 A
Voltage DC13 safety cont.	24 V
Safety contacts: AC at UL	240 VAC G. P.
Safety contacts: pilot duty	C300, R300
Relay contact material	AgSnO2
Addit. contact details relay	+ 0.2 µm Au

Climatic suitability to ...	EN 60068-2-78
Ambient temperature	-10 - 55 °C
Humidity rating	93 % r. h. at 40 °C
Condensation permitted?	Not permitted
EMC to standard ...	EN 60947-5-1 EN 61000-6-2 EN 61326-3-1
Vibration to standard ...	EN 60068-2-6
Clearance & creepage dist. to	EN 60947-1
Overvoltage category	III / II
Pollution degree clear.&creep.	2
Protection type, mounting
Protection type, housing
Terminal protection type
