Cảm biến quang IFM O5D150 Photoelectric distance sensor
Very long range due to time-of-flight measurement
Reliable background suppression and color-independent detection
With display and pushbuttons for precise switch point setting
...
| Product characteristics |
| Type of light |
red light |
| Laser protection class |
1 |
| Housing |
rectangular |
| Application |
| System |
Background suppression |
| Electrical data |
| Operating voltage [V] |
10...30 DC; (cULus - Class 2 source required) |
| Current consumption [mA] |
75; (24 V) |
| Protection class |
III |
| Reverse polarity protection |
yes |
| Type of light |
red light |
| Wave length [nm] |
650 |
| Typ. lifetime [h] |
50000 |
| Inputs / outputs |
| Number of inputs and outputs |
Number of digital outputs: 2 |
| Outputs |
| Total number of outputs |
2 |
| Electrical design |
PNP |
| Number of digital outputs |
2 |
| Output function |
normally open / closed; (complementary) |
| Max. current load per output [mA] |
100 |
| Switching frequency DC [Hz] |
11 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
yes (non-latching) |
| Overload protection |
yes |
| Monitoring range |
| Max. light spot diameter [mm] |
5 |
| Light spot dimensions refer to |
2 m |
| Detection range hysteresis [%] |
< 4 |
| Note on monitoring range hysteresis |
|
| Background suppression available |
yes |
| Background suppression [m] |
< 20 |
| Measuring/setting range |
| Measuring range [m] |
0.03...2 |
| Sampling rate [Hz] |
33 |
| Interfaces |
| Communication interface |
IO-Link |
| Transmission type |
COM2 (38,4 kBaud) |
| IO-Link revision |
1.1 |
| SDCI standard |
IEC 61131-9 |
| Profiles |
Smart Sensor: Sensor Identification; Binary Data Channel; Process Value; Sensor Diagnosis |
| SIO mode |
yes |
| Process data analog |
1 |
| Process data binary |
1 |
| Min. process cycle time [ms] |
6.6 |
| Supported DeviceIDs |
| Type of operation |
DeviceID |
| default |
372 |
|
| Operating conditions |
| Ambient temperature [°C] |
-25...60 |
| Note on ambient temperature |
| at ta < -10 °C warm-up is necessary, laser is off |
|
| Protection |
IP 65; IP 67 |
| Max. immunity to extraneous light [klx] |
10; (on the object) |
| Tests / approvals |
| EMC |
|
| Laser protection class |
1 |
| Notes on laser protection |
| Caution: |
Laser light |
| laser class: |
1 |
|
EN / IEC60825-1:2007 |
|
EN / IEC60825-1:2014 |
|
Complies with 21 CFR 1040 except for deviations pursuant to Laser Notice No. 50, dated June 2007. |
|
| MTTF [years] |
151 |
| Mechanical data |
| Weight [g] |
84.5 |
| Housing |
rectangular |
| Dimensions [mm] |
56 x 18.2 x 46.8 |
| Material |
housing: PA; Front framework: stainless steel; operator interface: TPU (urethane); lens: PMMA |
| Lens alignment |
Side sensing |
| Displays / operating elements |
| Display |
| Switching status |
LED, yellow Switching output PIN 4 |
| Power |
LED, green |
| Display |
alphanumeric display, 3-digit |
|
| Display unit |
cm |
| Remarks |
| Pack quantity |
1 pcs. |
| Electrical connection |
| Connection |
Connector: 1 x M12; coding: A |
