Cảm biến điện dung IFM IGS208 Inductive sensor

Cám ơn bạn đã quan tâm đến sản phẩm của NTN.
Yêu cầu báo giá xin click vào đây.

Mr. Nam:

0982494745

Model: IGS208

Maker: IFM

Description: Cảm biến

Cảm biến điện dung IFM IGS208 Inductive sensor

Robust metal housing for use in harsh industrial environments
Long sensing range minimizes physical damage
Clearly visible indication of the switching status
Operation as three-wire or...

Product characteristics
Electrical design	PNP/NPN
Output function	normally open
Sensing range [mm]	8
Housing	Threaded type
Dimensions [mm]	M18 x 1 / L = 70
Application
System	gold-plated contacts; Increased sensing range; optical setting aid
Application	Industrial applications
Electrical data
Operating voltage [V]	10...30 DC
Current consumption [mA]	12; (24 V)
Protection class	II
Reverse polarity protection	yes
Outputs
Electrical design	PNP/NPN
Output function	normally open
Max. voltage drop switching output DC [V]	2.8
Minimum load current [mA]	2; (only in 2-wire operation)
Max. leakage current [mA]	0.5; (only in 2-wire operation)
Permanent current rating of switching output DC [mA]	100
Switching frequency DC [Hz]	400
Short-circuit protection	yes
Type of short-circuit protection	yes (non-latching)
Overload protection	yes
Monitoring range
Sensing range [mm]	8
Real sensing range Sr [mm]	8 ± 10 %
Operating distance [mm]	0...6.5
Increased sensing range	yes
Accuracy / deviations
Correction factor	steel: 1 / stainless steel: 0.7 / brass: 0.5 / aluminum: 0.4 / copper: 0.3
Hysteresis [% of Sr]	3...15
Switch-point drift [% of Sr]	-10...10
Operating conditions
Ambient temperature [°C]	-25...70
Protection	IP 67

Cảm biến điện dung IFM IGS208 Inductive sensor
