Amplifier Keyence FS-V21 Bộ khuếch đại cảm biến

Amplifier Keyence FS-V21 Bộ khuếch đại cảm biến

Cám ơn bạn đã quan tâm đến sản phẩm của NTN.
Yêu cầu báo giá xin click vào đây.

Mr. Nam:

0982494745

Model: FS-V21

Maker: Keyence

Description: Bộ khuếch đại cảm biến

Certainly! The Keyence FS-V21R is a fiber amplifier designed for cable-type fiber optic sensors.

Type: Main unit with NPN output.
Light Source: Red LED.
Response Time:

FINE: 250 µs
TURBO: 500 µs
SUPER TURBO: 1 m...

FS-V21
kinds		Master unit / standard
Light source LED		red
Response time		250 µs (FINE) / 500 µs (TURBO) / 1 ms (SUPER TURBO) / 4 ms (ULTRA TURBO) / 500 µs (HIGH RESOLUTION) / 50 µs (HIGH SPEED)
Output switching		ON / ON switch switching when the light is on
Indicator light		・ Operation display: Red LED ^{* 1} ・ Dual digital monitor: Dual 7-segment display [Set value (green LED 4 digits) ・ Current value (red LED 4 digits) Simultaneous display, current value (0 to 65,520), detection margin (0 to 65,520) 0 P to 999 P)] ・ Hold function: Peak and bottom can be displayed at the same time ・ Bar LED monitor: Can be displayed at the same time as the current value [Detection margin (85 to 115% 7 levels) display]
Detection mode		Light intensity discrimination / rising edge / falling edge
Display shift function		Maximum ± 1,999 variable
Timer function	mode	Timer OFF / Off delay timer / On delay timer / One shot timer, variable timer time
	Setting range	1 to 30 ms: 1 ms increments, 30 to 50 ms: 2 ms increments, 50 to 200 ms: 10 ms increments, 200 to 500 ms: 50 ms increments
	accuracy	Maximum error to set value is ± 10% or less
Control output		NPN open collector 40 V, 100 mA or less ^{* 2} , residual voltage 1 V or less
